| Business Type | Exporter, Supplier, Trader |
| Brand Name | Gasmax |
| Model Number | GMCX |
| Permitted Liquids | LPG, Propane, Butane |
| Click to view more | |
Preferred Buyer From
| Location | Worldwide |
Product Details
Operating Temprature
-20°C to 85°C
Operational Voltage
440V
Heating Load
3KW to 150 KW
Vaporizing Capacity
30 Kg/hr to 1500 Kg/hr
Design Pressure
17 Bar
SRV Set Point
225 PSI
Proof Pressure
35 Bar
Inlet Connection size
Variable, Flanged #300 SORF
Temprature Sensor
PT - 100
Coil MOC
ASTM A312 Grade SS304
Tank MOC
IS 2062:2011
Insulation
LRB with Aluminium Cladding
CCOE Approval number
A/S/HQ/UP/PVM/16
PESO Approved LPG/NH3 Vaporizers
Material and specifications selection as per ASME BPVC VIII - ensuring safety.
Automatic heater cutoff on Low water level and Low temperature
Digital temprature control
LPG liquid level switch to ensure no liquid or debris in the line
Coated high thickness heating coils
PESO Approved to be used in tank and gas bank areas
Pressure switch for overpressure safety
Safety relief valve for excess pressure release
Armored cables and Flameproof equipment as per IS-60079
Flameproof/ Ex solenoid valve for liquid inlet control
